This Black 36 Horse Upright VW Fan Shroud with Ducts features 7 internal air directional baffles. With an Air-Cooled Volkswagen Engine these parts are very important. The fan pulls in air while the shroud creates a channeling effect to disperse it towards the oil cooler, cylinder heads, pistons & cylinders. The air ducts are in place for those that plan on keeping the original heater boxes and heating system.

Upright Fan Shrouds use a 30mm fan (part number 131119031) to push air through the shroud. Make sure to use the appropriate sized fan as the later model 36mm wide fan will not fit.

NOTE: 36 Horse Power refers to the style and shape of the fan shroud. This fan shroud is made for 1300-1600cc Type 1 based aircooled engines. As it is an aftermarket made piece it will not fit as well as original tin. No aftermarket tin will, period. If you want a factory fit, use the original factory pieces.
JBugs staff member Sam.

Our Expert's Take:

When it comes to engine tin, we always prefer original VW tin to aftermarket tin. For our 1971 Super Beetle restoration, we had our pick of the warehouse for the most part, and we used all original engine tin. Sometimes getting ahold of original pieces isn't feasible so there is a place for aftermarket engine tin. Aftermarket tin does not fit as well as original tin, period. Trimming, clearancing and occasionally drilling may be required to get the engine tin components to mount to the engine and other engine tin pieces. With work, the tin can be made to fit and be effective, but do not expect an OEM fit.
Sam


Aftermarket fan shrouds may have a gap at either side at the cylinder shrouds. The EMPI Aluminum Shroud Spacer Kit can be installed to ensure a tight fit for proper cooling.

California Prop 65 Warning: Cancer and Reproductive Harm
Please Note:The information listed below is for stock, unmodified VW's manufactured for sale in the US. VW's are commonly modified and very often parts from another year VW may have been installed on your car. California Pacific JBugs is not responsible for any errors if your car has been modified in any way.
VW Beetle
Sedan
1954 - 1977
Ragtop
1954 - 1963
Sunroof
1964 - 1977
Convertible
1954 - 1970
VW Super Beetle
Sedan
1971 - 1975
Convertible
1971 - 1979
VW Karmann Ghia
Coupe
1956 - 1974
Convertible
1957 - 1974
VW Type II (Bus)
Bus
1955 - 1979
Single Cab
1955 - 1979
Double Cab
1958 - 1979
1981 - 1982
VW Type 3
Squareback
1962 - 1973
Notchback
1962 - 1973
Fastback
1966 - 1973
VW Thing
Thing
1973 - 1974
Check what fan shroud you need before you buy. There's a good chance the parts which originally came on your vehicle have been swapped in the last 50 years. Both fan shrouds look similar from the front, but the back side reveals how these fan shrouds direct air through their oil coolers. Take a gander behind your fan shroud. Is there a DOGHOUSE attached to the back?

Upright Fan Shroud Back View
Doghouse Fan Shroud Back View

- Click to Read Fan Shroud Tech Article -
