EMPI 1968-70 VW Bus Disc Brake Conversion Kit - Front - 5x205

EMPI Type 2 Disc Brake Conversion Kit

• Converts 1968-1970 Type 2 Bus models from drum to disc brakes
• Bolts directly to stock spindles with heavy-duty caliper brackets
• Maintains compatibility with stock 5x205mm wheels
• Includes a master cylinder, brake hoses, bearings, seals, and installation hardware

EMPI's bolt-on disc brake kit converts 1968 through 1970 Type 2 Bus models from drum to disc brakes. The kit features heavy duty brake caliper brackets that bolt directly to your stock spindles and a 5x205mm disc brake rotor that accepts the stock 14x1.5mm lug bolts. A new master cylinder with reservoir, front brake hoses, bearings, seals, grease caps, a residual pressure valve and all necessary installation hardware including Loctite and wheel studs if you are not running stock wheels. The EMPI Type 2 Disc Brake Conversion Kit will clear stock Bus 14" VW wheels, and most all stock and aftermarket 15" and larger wide 5 VW wheels. Some cap clearancing may be needed on aftermarket wheels. The disc brake conversion kit will narrow the front track width 2.8mm. The master cylinder does not have a residual pressure valve so the kit includes an inline check valve and a brake line to be used for the rear drum brakes.

Note: This kit will narrow the front track width by 2.8mm. The master cylinder does not include a residual pressure valve, so the kit provides an inline check valve and brake line for the rear drum brakes.

Kit Includes

• 2 Inner wheel bearings and races
• 2 Inner grease seals
• 2 Outer wheel bearings and races
• 2 Wheel bearing thrust washers
• 2 Spindle lock nuts
• 2 Left & right front grease caps
• 2 Disc brake rotors
• 10 M14x1.5 lug studs
• 2 Left & right calipers
• 2 Left & right caliper brackets
• 8 M10x1.5x25 caliper bracket bolts
• 8 3/8" hardened flat washers
• 4 M12x1.5x40 caliper mounting bolts
• 4 Caliper bolt dust covers with installation tool
• 2 355mm flexible brake hoses
• 4 Disc brake pads with adhesive backing plates
• 1 Residual check valve
• 1 7.5" steel brake line
• 1 Caliper hardware kit
• 1 Master cylinder
• 1 Master cylinder reservoir
• 1 Caliper bolt dust cover installation tool
• 1 Loctite 430

Compatible Wheels

The stock 14" 5x205 wheel will fit this disc brake conversion kit. The following aftermarket wheels are also compatible:

• 9675 Matte Black BRM 15x5 (Must use 9704 Tall Cap)
• 9676 Gloss Black BRM 15x5 (Must use 9704 Tall Cap)
• 9729 Gloss Black BRM 15x6.5 (Must use 9704 Tall Cap)
• 9730 Chrome BRM 15x6.5 (Must use 9704 Tall Cap)
• 10-1086 Gloss Black BRM 17x7 (Must use 9704 Tall Cap)
• 10-1087 Chrome BRM 17x7 (Must use 9704 Tall Cap)
• 10-1108 Black & Silver Alloy 15x4.5 (Must use 10-1107 Cap, cap needs to be machined out to 60mm)
• 10-1109 Chrome Alloy 15x4.5 (Must use 10-1107 Cap, cap needs to be machined out to 60mm)
• 10-1110 Black & Silver Alloy 15x5.5 (Must use 10-1107 Cap, cap needs to be machined out to 60mm)
• 10-1111 Chrome Alloy 15x5.5 (Must use 10-1107 Cap, cap needs to be machined out to 60mm)
• 9750 Grey 5 Rib 15x5.5
• 9751 Chrome 5 Rib 15x5.5
• 9754 Grey Torque Star 15x5
• 9747 Machine Dish 15x5.5
• 9686 Chrome GT-5 15x5.5
• 9687 Polished GT-5 15x5.5
• 9690 Black GT-5 15x5.5
• 9691 Silver GT-5 15x5.5

Please Note

The 22-2940 Disc Brake Conversion Kit is only compatible with left-hand drive models.
