VW Engine Parts
Select a Sub-Category
VW Engine Parts for your Air-cooled Volkswagen, including VW 1600cc piston and cylinder kits, VW connection rods, 1600cc crankshafts, and Volkswagen cylinder heads are just some of the many Volkswagen engine parts that we offer.
VW Camshafts, Lifters, Crankshafts, Cylinder Heads, Engine Cases VW Engine Gasket Kits, Engine Rebuild Kits, Flywheels, Pistons VW Cylinders, Rings, Pushrods, Pushrod Tubes, Connecting Rods VW Rod Bearings, Main Bearings, Pulleys, Fans, Fan Accessories
ENGINE TORQUE SPECIFICATIONS | ||
|---|---|---|
| Fastners | ft. lbs | mkg. |
| Connecting Rod Nuts | 22-25 | 3.5 |
| Crankcase Nuts (12mm) | 18 | 2.5 |
| Crankcase Nuts (8mm) | 14 | 2 |
| Cylinder Head Nuts (10mm) | 23 | 3.2 |
| Cylinder Head Nuts (8mm) | 18 | 2.5 |
| Rocker Shaft Nuts | 14-18 | 2.5 |
| Crankshaft to Flywheel Bolt | 253 | 35 |
| Sump Screen Nuts | 5 | 0.7 |
| Oil Drain Plug | 25 | 3.5 |
| Oil Pump Nuts | 14 | 2 |
| Clutch to Flywheel Bolts | 18 | 2.5 |
| Spark Plugs | 22-29 | 4 |
| Generator Pulley Nut | 40-47 | 6.5 |
| Fan Nut | 40-47 | 6.5 |
| Crankshaft Pulley Bolt | 29-36 | 5 |
| Engine to Transmission | 22 | 3 |
ENGINE DISPLACEMENT TABLE | ||||||
|---|---|---|---|---|---|---|
| BORE | STROKE | ENGINE DISPLACEMENT IN CC's | ||||
| 64 | 69 | 74 | 76 | 78.4 | 82 | |
| 77 | 1192* | 1286** | 1378 | 1415 | 1460 | 1527 |
| 83 | 1385 | 1493+ | 1601 | 1644 | 1696 | 1774 |
| 85.5 | 1496 | 1584++ | 1699 | 1745 | 1800 | 1882 |
| 87 | 1521 | 1641 | 1759 | 1806 | 1863 | 1949 |
| 88 | 1556 | 1679 | 1799 | 1848 | 1906 | 1994 |
| 90.5 | 1646 | 1776 | 1903 | 1955 | 2016 | 2110 |
| 92 | 1700 | 1835 | 1967 | 2020 | 2084 | 2180 |
| 94 | 1776 | 1915 | 2052 | 2109 | 2175 | 2275 |
| * Stock 1200cc, **Stock 1300cc, +Stock 1500cc, ++Stock 1600cc | ||||||
